Audio Driver Diaphragms |
|
Photo |
Description |
Price |
Purchase |
Click on photo for
larger view |
Genuine Eminence Diaphragm
8 Ohms
REPLACEMENT 8-OHM AUDIO DIAPHRAGM. TITANIUM COMPRESSION DRIVER, 2" DIAMETER VOICE COIL, 80 WATTS, 8 OHM IMPEDANCE, 1,200-20,000HZ. USED IN MANY PROFESSIONAL HORN DRIVERS, INCLUDING YAMAHA AND CARVIN.
Part #
PSD2002-8DIA |
$39.95 |
Stock no:
PSD2002-8DIA
8 Ohms
$39.95
|
Click on photo for
larger view |
Genuine Eminence Diaphragm
16 Ohms
REPLACEMENT 8-OHM AUDIO DIAPHRAGM. TITANIUM COMPRESSION DRIVER, 2" DIAMETER VOICE COIL, 80 WATTS, 16 OHM IMPEDANCE, 1,200-20,000HZ. USED IN MANY PROFESSIONAL HORN DRIVERS, INCLUDING YAMAHA AND CARVIN.
Part #
PSD2002-16DIA |
$39.95 |
Stock no:
PSD2002-16DIA
16 Ohms
$39.95
|
For crossover capacitors, see our crossover capacitor web page
|
 |
Super Tweeter
- 8 ohms
3-1/2" x 3-1/2" flush mount
Magnet: 5.4 ounces
Voice Coil: 1"
Rated at 300W Peak
Sensitivity: 105dB
Frequency Response: 2KHZ - 20KHz
Requires crossover or in-series non-polarized capacitor - see the
crossover capacitor web page
Part #HP-43A |
$10.95 |
We only have one of these left in stock! |
|
Speaker Repair
Accessories & Supplies |
 |
Speaker
Protection Fuse Lamp
Used in many pro audio crossover circuits to help protect the driver.
As the audio power increases, this device heats up (and even lights up at high
power levels). As it heats its resistance increases, thereby reducing the
audio power reaching the driver. This version may be snapped into holders
on the crossover PC board, or have wires soldered to the end loops for soldering
onto a PC board. Peavey part number 30902306, for use in Peavey
LQ15, PR15, PV12M, PV115, PV215, SP2, SP4, SP5. Electro-Voice part
number F.01U.109.425, for use in EV G115, ZX4, ZX5, ELX115. Eminence
part number PX-BULB (two SPF-211 soldered together) Size 10mm (3/8") x 38mm (1.5")
Part # SPF-211 |
$3.99 |
|
 |
 Speaker
Protection Fuse
This is slightly
smaller than the SPF-211.
Used in many pro audio crossover circuits to help protect the driver - this size
is commonly found in Peavey.
As the audio power increases, this device heats up (and even lights up at high
power levels). As it heats its resistance increases, thereby reducing the
audio power reaching the driver. This version only may be snapped into holders
on the crossover PC board. It is not designed to work with hard-soldered fuse
types. Size 8.3mm (5/16") diameter of the end caps x 38mm (1.5")
long.
Part # E-211 |
$1.99 |
|
Click on photo for
larger view |
L-PAD FACE PLATE AND KNOB, for 3/8" diameter threaded bushing found on most L-Pad Level
controls. Face plate AND knob only! L-Pad ordered separately.
Fits many bass
cabinets including the SWR Goliath, Marcus Miller Golight 410, Workingman
8x10, Working Pro 2x10, Ampeg PN-210HLF, PN-410HLF, SVT-410HLF, SVT-610HLF,
SVT-810SPC, BXT210M,
BXT410HL4, PR-1528HE, PN-115HLF, PR-810H, PB-250, the Kustom G410H, the
Engl B115 as well as many others.
This is the face plate and knob only - L-PAD itself ordered separately.
Raised lettering in charcoal gray instead of white. 3 1/8 inches in
diameter, 7/8 inch depth into cabinet. Requires 2 inch diameter hole
for mounting. Screws not included.
Part #LFP-380 |
$3.99 |
|
8 Ohms
Click on photo for
larger view |
L-PAD, 8 Ohms, 3/8" threaded bushing (3/8" long), with plate, knob and hardware.
May also be used with the LFP-380 face plate and knob. 8 ohms
- for use with 8 ohm speakers, horn drivers or tweeters.
L-pads adjust the relative volume of drivers connected to them by placing added
resistance in series and parallel, keeping impedance a constant 8 ohm load. This
L-pad is rated at 100 watts RMS, is designed to be used with 8 ohm loads,
features a 3/8" shaft length, and comes with mounting hardware. This
style of L-Pad is found on many popular bass cabinets to control the
horn/tweeter level. 2.5 inches in diameter, 1 inch thick.
Included face plate is 2 1/8" x 2 1/8".
Part #LPD-262 |
$17.95 |
|
16 Ohms
Click on photo for
larger view |
L-PAD, 16 Ohms, 3/8" threaded bushing (3/8" long), with plate, knob and hardware.
May also be used with the LFP-380 face plate and knob. 16 ohms - for
use with 8 ohm speakers, horn drivers or tweeters.
L-pads adjust the relative volume of drivers connected to them by placing added
resistance in series and parallel, keeping impedance a constant 8 ohm load. This
L-pad is rated at 100 watts RMS, is designed to be used with 16 ohm loads,
features a 3/8" shaft length, and comes with mounting hardware. This
style of L-Pad is found on many popular bass cabinets to control the
horn/tweeter level. 2.5 inches in diameter, 1 inch thick.
Included face plate is 2 1/8" x 2 1/8".
Part #LPD-261 |
$17.95 |
|
Click on photo for
larger view |
 Revisit™ FenderŪ
STYLE SPEAKER HARNESS - VINTAGE
This is the real deal, if you want your vintage FenderŪ to be as "vintage" as
possible. Replacement vintage style FenderŪ right-angle plug with FenderŪ "F-Cap". 18"
vintage style white and black twisted cable with cloth insulation
 and 3/16" fast-on connectors.
Used to replace speaker cable in most FenderŪ blackface and silverface amplifiers
with one or two speakers.
Part #FSH-191 |
$19.99 |
|
Click on photo for
larger view |
Revisit™ FenderŪ
STYLE SPEAKER CABLE HARNESS - VINTAGE - 12" LONG
This is the real deal, if you want your vintage FenderŪ to be as "vintage" as
possible. Replacement vintage style FenderŪ speaker cable with metal RCA
plug, 3/16" fast-on connectors and 12" vintage style
white and black twisted
cloth insulated cable.
Used to replace speaker cable in most vintage FenderŪ blackface and silverface
Champ, Bronco, or VibroChamp amplifiers.
Part #FSH-120 |
$14.99 |
|
Click on photo for
larger view
|
Revisit™ FenderŪ
STYLE SPEAKER CABLE HARNESS - VINTAGE - 12" LONG, WITH REPLACEMENT RCA JACK
Replacement vintage style FenderŪ speaker cable with metal RCA
plug, 3/16" fast-on connectors and 12" vintage style white and black twisted
cloth insulated cable. Also
includes replacement phenolic RCA
speaker jack.
Used to replace speaker cable and speaker jack in most vintage FenderŪ blackface and silverface
Champ, Bronco, or VibroChamp amplifiers.
Part #FCJC-120 |
$16.99 |
|
Click on photo for
larger view |
Revisit™ FenderŪ
STYLE SPEAKER CABLE HARNESS - VINTAGE - 18" LONG
This is the real deal, if you want your vintage FenderŪ to be as "vintage" as
possible. Replacement vintage style FenderŪ speaker cable with metal RCA
plug, 3/16" fast-on connectors and 18" vintage style white and black twisted
cloth insulated cable.
Used to replace speaker cable in most vintage FenderŪ tweed amplifiers.
Part #FSH-180 |
$15.99 |
|
Click on photo for
larger view
|
Revisit™ FenderŪ
STYLE SPEAKER CABLE HARNESS - VINTAGE - 18" LONG, WITH REPLACEMENT RCA JACK
Replacement vintage style FenderŪ speaker cable with metal RCA
plug, 3/16" fast-on connectors and 18" vintage style white and black twisted
cloth insulated cable. Also
includes replacement phenolic RCA
speaker jack.
Used to replace the speaker cable and speaker jack in some vintage FenderŪ tweed
style amplifiers from the 1950s.
Part #FTJC-180 |
$17.99 |
|
Click on photo for
larger view
|
Revisit™ FenderŪ
STYLE SPEAKER HARNESS - VINTAGE
This is the real deal, if you want your vintage FenderŪ to be as "vintage" as
possible. For FenderŪ amps with two speakers that need the complete
speaker wiring replaced (Pro Reverb, Twin Reverb, Vibrolux Reverb, etc) Replacement vintage style FenderŪ right-angle plug with FenderŪ "F-Cap". 18"
vintage style white and black twisted cable with cloth insulation and 3/16" fast-on connectors.
Additional 19" cloth-insulated jumper with fast-on connectors used to bridge the two speakers
together.
Used to replace speaker cable in most FenderŪ blackface and silverface amplifiers
with two speakers.
Part #FSH-192 |
$27.99 |
|
Click on photo for
larger view
|
Revisit™ FenderŪ
STYLE SPEAKER JUMPER - VINTAGE
This is the real deal, if you want your vintage FenderŪ to be as "vintage" as
possible. For FenderŪ amps with two speakers in parallel, this is the
jumper that connects the speakers to each other. (Pro Reverb, Twin Reverb, Vibrolux Reverb, etc) 19"
vintage style white and black twisted cable with cloth insulation and 3/16" fast-on connectors
on each end.
Used to replace speaker jumper in most FenderŪ blackface and silverface amplifiers
with two speakers. For speakers wired in series, the two wires
may be easily separated so that one wire can be used as the jumper.
Part #FSJ-190 |
$7.99 |
|
Click on photo for
larger view
|
Revisit™ FenderŪ
STYLE 'SPIDER' SPEAKER HARNESS FOR SUPER REVERB - VINTAGE
Replacement vintage style FenderŪ right-angle plug with FenderŪ "F-Cap".
Prewired to the distribution connector which is to be mounted in the center of the
Super Reverb cabinet. From there, 4 separate wire runs, one for each
10" speaker. Painstakingly made to reproduce the look and feel of the
original: Cloth-covered white and black 18ga wire, fiber spider
distribution connector, F-Cap type plug with the FenderŪ "F" logo.
Used to replace the complete speaker harness in most FenderŪ blackface and silverface
Super Reverb amplifiers from the 60's and 70's. Just screw
down the spider distribution connector inside the cabinet, solder the wire to
the 4 10" speakers, and plug into the rear of the amplifier.
Part #FSH-724 |
$39.99 |
|
Click on photo for
larger view
|
Revisit™ FenderŪ
STYLE 'SPIDER' SPEAKER HARNESS FOR 2X10 or 2X12 COMBO AMPS - VINTAGE
Replacement vintage style FenderŪ right-angle plug with FenderŪ "F-Cap".
Prewired to the distribution connector which is to be mounted in the center of the
cabinet. From there, 2 separate wire runs, one for each speaker. Painstakingly made to reproduce the look and feel of the
original: Cloth-covered white and black 18ga wire, fiber spider
distribution connector, F-Cap type plug with the FenderŪ "F" logo.
Used to replace the complete speaker harness in most FenderŪ blackface and silverface
Pro Reverb, Twin Reverb, Vibrolux Reverb, Vibroverb amplifiers from the 60's and 70's. Just screw
down the spider distribution connector inside the cabinet, solder the wire to
the two speakers, and plug into the rear of the amplifier.
Part #FSH-608 |
$33.99 |
|
Click on photo for
larger view |
FenderŪ Vintage Style Speaker Cable - Various
Lengths
Designed for vintage FenderŪ heads and cabinets, such as Bassman, Bandmaster,
Tremolux, Showman, Dual Showman, etc, from the Blonde, Blackface and Silverface
eras. Brown 18 gauge parallel zip cord,
with two FenderŪ
traditional right-angle plugs with the iconic "F-Caps" containing the FenderŪ "F"
logo. Available in 24, 30, 36, 42, and 48 inch lengths. Choose
your length under "Options". Important:
Measure the distance between the amp head speaker output jack and the speaker cabinet jack and add a minimum of 6
inches for slack.
Part #FVSC-X |
24 inches - $27.95
30 inches - $28.50
36 inches - $28.95
42 inches - $29.50
48 inches - $29.95 |
|
Click on photo for
larger view |
Revisit™ SPEAKER CABLE - HEAD TO CABINET -
4 FEET LONG
Black 4 feet 16 gauge speaker cable, with one straight 1/4 inch plug and one
right-angle 1/4 inch plug. Used to connect amplifier head to
cabinet.
Part #SCH-7028 |
$4.99 |
|
Click on photo for
larger view |
UNIVERSAL CABLE TESTER, 9 PLUG TYPES This
professional cable tester quickly tests for continuity and/or conductor shorts for all types of cables in various plug
combinations. Rugged metal construction provides durability and reliability
making it handy to bring to the jobsite. Rotary 9-way switch for easy selection
of cables to be tested and internal battery and ground connection status check.
Tests cables with the following connections: 3.5mm jack (mono & stereo), ž” jack
(mono & stereo), 3 and 5 pin XLR (male & female), RCA phono, Banana plugs,
3-pin, 5-pin and 8-pin DIN jacks, 4-pin small DIN (S-Video) jack, 4 and 8-pin Speakon. Requires 9V battery (not included). Soundlab model CT-04, Tenma
Model 72-8785.
Part #CT-04 |
$37.95 |
|
Click on photo for
larger view |
SPEAKER JUMPER CABLE
Teflon™ insulated silver plated copper speaker wire, 18 gauge, twisted pair,
black and white. Terminated at each end in standard 3/16" speaker
fast-on connectors. Great for connecting speakers in parallel in
2x12 or 4x12 cabinets. 24 inches (61 cm) long. Made in
USA.
Part #SJ-150 |
$5.99 |
|
Click on photo for
larger view |
Revisit™
SPEAKER HARNESS, 2 ft LONG,
PUSH-ON TERMINALS, 16 GAUGE CABLE
Replacement right-angle plug with 24" cable and 3/16" fast-on connectors.
Used to replace speaker cable in many combo amplifiers where the speakers are
connected to the amplifier chassis via a 1/4" jack and plug.
Heavy-duty 16ga round black speaker cable,
right-angle plug and fast-on connectors for attachment to one
speaker.
Part #SCH-7080 |
$4.50 |
|
Click on photo for
larger view |
Revisit™
SPEAKER HARNESS
Replacement right-angle plug with 34" cable and 3/16" fast-on connectors.
Used to replace speaker cable in most combo amplifiers where the speakers are
connected to the amplifier chassis via a 1/4" jack and plug. 18ga black zip cord,
right-angle plug and fast-on connectors for attachment to one
speaker.
Part #SCH-280 |
$5.99 |
|
Click on photo for
larger view |
Revisit™ SPEAKER HARNESS COMPLETE
WITH GENUINE SWITCHCRAFT #11 JACK and 24" SPEAKER WIRE FOR SINGLE SPEAKER.
Preassembled for speaker cabinets with one
speaker. Includes Switchcraft #11 jack,
and 24 inch Teflon™-insulated 18 ga speaker wire terminated in 3/16" push-on
speaker connectors. For two-speaker cabinets, see the SCH-2411X2,
below.
Part #SCH-2411 |
$8.99
|
|
Click on photo for
larger view |
Revisit™ SPEAKER HARNESS COMPLETE
WITH GENUINE SWITCHCRAFT #11 JACK and 24" SPEAKER WIRE FOR TWO SPEAKER
CABINET.
Preassembled for speaker cabinets with two
speakers in parallel. Includes Switchcraft #11 jack,
and 24 inch Teflon™-insulated 18 ga speaker wire terminated in 3/16" push-on
speaker connectors, plus an additional 24" jumper cable.
Part #SCH-2411X2 |
$14.99
|
|
Click on photo for
larger view |
Revisit™ SPEAKER HARNESS COMPLETE
WITH 1/4" STRAIGHT PLUG and 24" SPEAKER WIRE FOR SINGLE SPEAKER.
Preassembled for combo amps with one
speaker. Includes 1/4" straight plug,
and 24 inch Teflon™-insulated 18 ga speaker wire terminated in 3/16"
push-on speaker connectors. For 2-speaker cabinets, add the SJ-150 jumper,
below.
Part #SCH-224 |
$9.99
|
|
Click on photo for
larger view |
Revisit™ SPEAKER HARNESS COMPLETE
WITH 1/4" RIGHT-ANGLE PLUG and 24" SPEAKER WIRE FOR SINGLE SPEAKER.
Preassembled for combo amps with one
speaker. Includes 1/4" right-angle plug,
and 24 inch Teflon™-insulated 18 ga speaker wire terminated in 3/16"
push-on speaker connectors. For 2-speaker cabinets, add the SJ-150
jumper, below.
Part #SCH-287 |
$9.99
|
|
Click on photo for
larger view |
Revisit™
SPEAKER JUMPER CABLE
Teflon™ insulated silver plated copper speaker wire, 18 gauge, twisted pair,
black and white. Terminated at each end in standard 3/16" speaker
fast-on connectors. Great for connecting speakers in parallel in
2x12 or 4x12 cabinets. 24 inches (61 cm) long. Made in
USA.
Part #SJ-150 |
$5.99 |
|
Click on photo for
larger view |
Revisit™
JACK PLATE COMPLETE WITH
SWITCHCRAFT #11 JACK.
Switchcraft #11 jack preinstalled with lock washer and trim washer.
Outside diameter 2
inches (51mm). Designed to fit flush against a 1 1/8" (29mm) cabinet hole.
Easy to install - drill 1 1/8" hole in cabinet, attach speaker wiring to jack
and speaker, attach plate to cabinet.
Part #JPC-180 |
$3.95
|
|
Click on photo for
larger view |
Revisit™ JACK PLATE COMPLETE
WITH GENUINE SWITCHCRAFT #11 JACK and 24" SPEAKER WIRE.
Preassembled - includes 2" diameter single jack mounting plate with Switchcraft #11 jack preinstalled with lock washer and trim washer,
and 24 inch Teflon™-insulated 18 ga speaker wire terminated in 3/16" push-on
speaker connectors. Outside jack
plate diameter 2
inches (51mm). Designed to fit flush against a 1 1/8" (29mm) cabinet hole.
Easy to install - drill 1 1/8" hole in cabinet, attach speaker wiring to
speaker,
attach plate to cabinet. For two-speaker cabinets, see the JPH-182,
below.
Part #JPH-180 |
$10.95
|
|
Click on photo for
larger view |
Revisit™ JACK PLATE COMPLETE
WITH GENUINE SWITCHCRAFT #11 JACK and 24" SPEAKER WIRE, PLUS ADDITIONAL 24"
JUMPER.
Preassembled - includes 2" diameter single jack mounting plate with Switchcraft #11 jack preinstalled with lock washer and trim washer,
and 24 inch Teflon™-insulated 18 ga speaker wire terminated in 3/16" push-on
speaker connectors. Outside jack
plate diameter 2
inches (51mm). Designed to fit flush against a 1 1/8" (29mm) cabinet hole. Includes
a second 24 inch Teflon™-insulated 18 ga speaker wire terminated in 3/16"
push-on speaker connectors to connect to a second speaker in the same cabinet.
Easy to install - drill 1 1/8" hole in cabinet, attach speaker wiring to
speakers,
attach plate to cabinet.
Part #JPH-182 |
$15.95
|
|
